Double Colour Sheet Fed Offset Machine

3500000 INR/Unit

Get a Price/Quote

Product Details:

Type Double Colour Sheet Fed Offset Machine
Material Steel
Computerized No
Automatic Grade Automatic
Weight (kg) 4150 Kilograms (kg)
Warranty 1 Year
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Double Colour Sheet Fed Offset Machine Price And Quantity

Minimum Order Quantity 1 Unit
Price 3500000 INR/Unit

Double Colour Sheet Fed Offset Machine Product Specifications

Automatic Grade Automatic
Weight (kg) 4150 Kilograms (kg)
Type Double Colour Sheet Fed Offset Machine
Warranty 1 Year
Computerized No
Material Steel

Product Description

Standard Features:

Lateral and circumferential running registration systems.
Pendent to facilitate emergency impression trip off, inching forward and reverse, at every station.
Centralized greasing system for all gripper shafts on both ends.
Dampening water re-circulation system.
Automatic centralized oil lubrication system.
Anti set-off powder spray system.
Compact main control panel, DC variable speed drive mechanism with digital sheet counter, speedometer.
Mechanical no-sheet and double sheet detector fitted for smooth feeding and safe feeding of paper.
All Gears of Romeo sheetfed offset printing equipment are of EN-353 hardened and well grounded.
All transfer cylinders of Romeo sheet-fed offset printing equipment are covered with /glass wool coated cloth for scratch-less printing.
Crawling speed for blanket Er plate cleaning.
Max. size of printing : BPL-25/225/425 (18" x 25")(45cm x 62.5cm)
Max. size of printing : BPL-28/228/428 (18"x 28" = 45errix 71.5 cm)

Option-

Alcohol / Water dampening with BALDWIN Basicliner Fountain solution premixing with EN- 353 hardened bearer rings.

Specification

	BPL 225	BPL 228
Largest paper Format	460 X 640 mm	460 X 715 mm
Smallest paper Format	240 X 280 mm	240 X 280 mm
Max. Print Area	445 X 636 mm	445 X 711 mm
Gripper Margin	30 mm	30 mm
Plate Size	510 X 645 X.30 mm	510 X 720 X.30 mm
Blanket Size	570 X 645 X 1.7 mm	570 X 725 X 1.7 mm
No. of Rollers	20	20
No. of Ink Form Rollers	3	3
Diameters of Ink Form Rollers	58, 63, 70 mm	58, 63, 70 mm
No. of Dampening Rollers	5	5
Speed (Impression Per Hour)	2000 to 7000 iph	2000 to 7000 iph
Pile Height, Feeder	800mm	800mm
Pile Height, Delivery	410mm	410mm
Minimum Gripper Bite	5 to 8 mm	5 to 8 mm
Floor Space required )LxWl	2600x2350	2600)(2425
Height	1650 mm	1650 mm
Net Weight	4150 kg,	4500 kg.
Power Required	3.75 KW - 5HP	3.75 KW - 5HP
Stock Range	40gsm to 400gsm	40gsm to 400gsm
