BPL printing machines are well supported by skill full and experienced persons stationed at branch offices strategically placed at major cities all over the India. Every branch is equipped with an expert team of experienced service engineers who are geared to build up an indisputably strong network of customer services.
Machine size
|
BPL 18x25
|
BPL18x28
|
BPL20x30
|
BPL22x32
|
BPL23x36
|
BPL28x40
|
Sheet Size (max)
|
18.5"x25.5"
|
18.5"x28.5"
|
18.5"x28.5"
|
22"x32"
|
24.5"x37"
|
28"x40"
|
Sheet Size (min)
|
9"x10"
|
9"x10"
|
10"x11"
|
11"x13"
|
12"x14"
|
12"x14"
|
Printing area (max)
|
17.5"x25"
|
17.5"x28"
|
19.5"x30"
|
21"X31"
|
23"x36"
|
27"x40"
|
Gripper Margin on Paper
|
9mm
|
9mm
|
9mm
|
9mm
|
9mm
|
9mm
|
Gripper Margin on plate
|
1.25"
|
1.25"
|
1.25"
|
1.25"
|
1.25"
|
1.25"
|
Plate size
|
20"x26"
|
20"x29"
|
22"x31"
|
24"x32"
|
26"x38"
|
31"x40"
|
Plate thickness
|
0.2mm
|
0.3mm
|
0.3mm
|
0.3mm
|
0.3mm
|
0.3mm
|
Blanket size
|
22"x26"
|
22"x29"
|
24"x31"
|
26"x32"
|
26"x32"
|
32"x41"
|
Pile height feeder
|
32
|
32
|
32
|
32
|
32
|
32
|
Pile height delivery
|
16
|
16
|
17
|
18
|
18
|
18
|
Paper thickness (gsm)
|
30-450
|
30-450
|
30-450
|
30-450
|
30-450
|
30-450
|
No. of inking rollers
|
120
|
120
|
120
|
120
|
120
|
120
|
No. of dampening rollers
|
30
|
30
|
30
|
30
|
30
|
30
|
No. of ink form rollers
|
18
|
18
|
18
|
18
|
18
|
18
|
Main drive motor
|
15HP
|
15HP
|
18HP
|
25HP
|
25HP
|
30HP
|
Compressor pump motor
|
2HP
|
2HP
|
3HP
|
3HP
|
5HP
|
7.5HP
|
Speed max.
|
8000 IPH
|
8000 IPH
|
7000 IPH
|
7000 IPH
|
7000 IPH
|
7000 IPH
|
Physical dimension (inches)
|
363x57x60
|
366x57x60
|
369x63x70
|
372x65x75
|
374x66x80
|
379x70x86
|
Weight
|
10600kg
|
11800 kg
|
13400 kg
|
17000 kg
|
21800 kg
|
25400 kg
|
