Model |
BPL 222 S |
BPL 224 S |
---|---|---|
Dimension |
97 inch L x 45 inch W x 57 inch |
103 inch L x 50 inch W x 60 inch |
Weight |
1250 Kg (Approx) |
1400 Kg |
Power Requirements |
200 to 240 AC |
200 to 240 AC |
Maximum Paper Size |
16.5 inch W x 22.5 inch L |
18.5 inch W x 24.5 inch L |
Minimum Paper Size |
5 inch W x 7 inch L |
W x 7 inch L |
Maximum Image Area |
15.5 inch W x 22 inch L |
17.5 inch W x 24 inch L |
Paper Weight |
40-400 GSM |
40 to 400 GSM |
Blanket Thickness |
1.9 mm |
1.9 mm |
|
(4 Ply Rubber Blanket) |
(4 Ply Rubber Blanket) |
Blanket size |
19.5 inch x 23 inch |
19.5 inch x 23 inch |
Plate Size |
17.5 inch x 23 inch |
17.5 inch x 23 inch |
Plate Thickness |
0.3 |
0.3 |
Gripper Margin on paper |
8 to 10 mm |
8 to 10 mm |
Gripper Margin on plate |
1.25 inch |
1.25 inch |
Feeding System |
Suction Feeding |
Suction Feeding |
Ink Roller |
14/2 Ink Roller |
14/2 Ink Roller |
|
Includes : 3 Oscillators |
Includes : 3 Oscillators |
Dampening Rollers |
5/5/4 From Rollers |
5/5/4 From Rollers |
Printing Speed : on paper |
1500to3500 IPH |
1500to5000 IPH |
Printing Speed : on Bags |
1500to3500 IPH |
1500to3500 IPH |
Main Drive Motor |
2 HP Single Phase |
3 HP Single Phase |
Compressor Pump Motor |
1.5 HP Single Phase |
1.5 HP Single Phase |
