Product Description
Specification of 4 color Flexo Printing machine
Performance The machine adopts rubber plate as of plate printing machine suitable for printing roll material such packing materials as nonwoven fabric roll paper paper packing bag Kraft Paper and Duplex paper etc
Easy operation flexible starting accurate color register
The meter counter can set printing quantity according to the requirements Stop the machine automatically at the quantity or when the material is cut off
Pneumatic printing cylinder lift and lower it will stir the printing ink automatically after lifting
The printing ink is spread by the Flexo cylinder with Waterbase ink color
Reliable drying system coordinated with highspeed rotation it will automatically break circuit when the machine stops
360 continuous and adjustable longitudinal register device
The frequency control of motor speed adapts to different printing speeds
There are JoggingStopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed
Magnetic powder or manually brake for unwinding tension control Magnetic powder clutch for rewinding tension control
Main Specification Of The Machine
ModelBPL4 1200mm AND AS PER CUSTOMIZED
Printing MachineNon woven fabric roll paper Kraft paper Duplex Paper and so on
Max Printing Width 1200mm and as per customized
Max Printing Length1001000mm AND AS PER CUSTOMIZED
Mechanical Speed 1080mm
Printing Speed1060mm
Image Plate Thickness include adhesive tape28mm
Feeding Material Unit
Reel Length1200mm AND AS PER CUSTOMIZED
Valid printing reel length1200mm AND AS PER CUSTOMIZE
Reel core diameter 76mm
Max diameter of feeding Material 1078mm
Feeding mode magnetic powder brake auto tension feeding with photocell side correction
Pulling Unit
Pulling part belt roller chroming roller
Group 4 groups
Printing Unit
Printing part chroming roller printing roller rubber roller
Printing roller circumference 1001000mm
Printing plate material PVC rubber
Drive mode gear drive
Printing 360 degree rotate
Adjust mode manual
Plate Lifting manual
Heating Dry Part
Heat drying system blower with heating
Heating area 4 color 6 pieces
Heating power 1500mm Model 5kw
Assistant drying length 1 meter
Fan2 pieces
Blowing powder 1200mm 211kw
Motor Unit
Main motor 4color 1200mm 3kw
Running ink motor 4 color 1200mm 075kw
Main motor adopt frequency control adjusting speed
Rewinding Part
Reel length 1200mm
Valid reel 1200mm
Reel core diameter 76mm
Max feeding diameter 1000mm
Rewinding mode magnetic powder auto tension control rewinding
Main Detailed Parts List
Main Motor1pc 3Kw
Inking motor1pc 075kw
Inverter1 set Japan
Fan2pcs 11Kw APP
Aluminum guide roller BST SYONA investment surface oxidation static and dynamic equalization treatment
Metal roller each color one piece
Rubber roller one color one piece
Brake powder one set
Lowvoltage appliance Omron
Switch France Schneider
Electric control case Local
Main Machine Body
Machine cast
Bearings Japan USK
Pneumatic elements JENETICS
Powder brake and Tension controller Japan Mitsubishi AND INDIAN
